| Type | AS-4173-1 | AS-4153-1 | AS-5255-2 | AS-5253-4 | AS-5174-1D | AS-5185-2 | AS-5164-1 | |
|---|---|---|---|---|---|---|---|---|
| Pre-solidified characteristics | ||||||||
| viscosity (cps,25℃)(A solution) | cps | 5,000 | 3,800 | 3,500 | 3,000 | 5,000 | 5,000 | 4,500 |
| viscosity (cps,25℃)(B solution) | cps | 2,300 | 2,300 | 6,500 | 6,000 | 5,000 | 6,000 | 4,500 |
| Mixed viscosity (cps,25℃) | cps | 3,000 | 3,000 | 5,500 | 5,000 | 5,000 | 5,500 | 4,500 |
| Mixing ratio | 1:1 | 1:1 | 1:2 | 1:4 | 1:1 | 1:2 | 1:2 | |
| Pot life(25 ℃) | hrs | 12 | 12 | 12 | 12 | 12 | 12 | 12 |
| solidifying condition | ℃/hr | 60℃*1hr | +150℃*2~3hr | / | 40℃*1/2hr | +110℃*1/2hr | +150℃*2~3hr | |
| Solidified characteristics | ||||||||
| Hardness (Shore) | shore | A70 | A50 | A50 | D38 | A70 | A79±5 | A60±5 |
| Refractive index | n | 1.41 | 1.53 | 1.53 | 1.53 | 1.54 | 1.54 | 1.54 |
| transparency | % | > 95 | > 95 | > 98 | > 98 | > 98 | > 98 | > 98 |
| Tg | ℃ | -105.1 | -111.8 | 13 | -4..8 | 12.1 | 11.8 | 15.3 |
| P/N | Color.......................... | Mixing ratio | Mixed viscosity (cps,25℃) | Hardness (Shore) | Features and applications................................................................................... |
|---|---|---|---|---|---|
| SC-129 | Grey | 1:1 | 2,500~5,000 | A 45 | Low viscosity, good leveling, low shrinkage, excellent electrical properties for potting |
| SC-711 | Clear | 1:1 | 300~500 | A 26 | High clarity, low stress, for solar cells and opto-electronic displays |
| SC-738 | Clear | 1:1 | 2,000 | A 18 | High clarity, low stress, for solar cells and opto-electronic displays |
| SC-722 | Translucent | 1:1 | 1,800~2,400 | 00 < 0 | Fast cure, low stress gel, for shockproof of electronic components |
| SC-725 | Clear | 1:1 | 550 | 00 < 0 | High clarity, low stress gel, for shockproof of electronic components |
| SEG series | Clear | 1:1 | 200~100,000 | 00 < 0 | High clarity, low stress gel, for shockproof of electronic components |
| SFY-131 | Black,Grey | 1:1 | 4,000 | A 60 | UL94V0 approval, good leveling, low shrinkage, excellent electrical properties and good thermal conductivity for flame resistant potting |
| SFY-161 | Grey | 1:1 | 6,000 | A 57 | UL94V0 approval, low shrinkage, excellent thermal stability, high thermal conductivity, for flame resistant potting |
| SFY-171 | Black | 1:1 | 5,000 | A 51 | Low viscosity, UL94V0 approval, low shrinkage, excellent thermal stability, high thermal conductivity, low stress, for flame resistant potting |
| SAH-220F | Black, grey, white | 1:1 | 18,000 | A 30 | General potting, good mechanical properties, dual-pack easy use, fast cure |
| SAH-721 | Blue, grey, white, red | 1:1 | 8,000 | A 65 | General potting, high durometer |
| STC-913
| White | 1:1 | 70,000 | A 80 | High conductivity 1.5W/mK for potting, long pot life |
| 品名 | 顏色 | 比例 | 混合黏度 | 硬度 | 特性及用途............................................................................................... |
|---|---|---|---|---|---|
| SO-216 | Black, white | 3 : 1 | 3,000 | A 35 | Excellent adhesive properties. |
| SO-216C | Translucent | 3 : 1 | 2,000 | A 16 | Excellent adhesive properties. |
| SO-220 | Black, white | 5 : 1 | Semi-sag | A 40 | Semi-sag, excellent adhesive properties. |
| SO-305 | Black, white | 4~20:1 | 5,000 ~14,000 | A24 ~ 40 | Excellent adhesion properties, flexible mix ratios, potting. |
| SO-305S | Black, white | 10:1 | 5,000 | 00: 35 | Low stress, excellent adhesion properties. |
| P/N | Color | Mixing ratio | (cps,25℃)Viscosity | Hardness (Shore) | Features and Applications .......................................................................... |
|---|---|---|---|---|---|
| SCK-33 | Clear | 80:20:10 | 600 | A65 | High gloss, high transparency, yellowing resistance, for silicone surface coating. |
| SC-412 | Clear | 20:1 | 1,000 | A26 | High clarity, yellowing resistant, for clear potting. |
| SC-418 | Clear | 20:1 | 6,000 | A18 | High transparency, yellowing resistance for clear potting/casting. |
| SC-420 | Clear | 30:1 | 18,000 | A25 | High transparency, yellowing resistance for clear potting/casting. |
| SSL-310 | Clear | 10:1 | 1,000 | A15 | High clarity, good mechanical strength and adhesion properties, for solar cells and optoelectronic displays. |
| SSL-311 | Clear | 10:1 | 2,800 | A15 | High clarity, good mechanical strength and adhesion properties, for solar cells and optoelectronic displays. |
| SSL-302 | Clear | 10:1~20:1 | 1,500 | A 27~A 20 | High clarity, good adhesion properties and weather resistance for solar cells and optoelectronic displays. |
| P/N | Color | Mixing ratio | (cps,25℃)Viscosity | Hardness (Shore) | Features and applications....................................................... |
|---|---|---|---|---|---|
| SCM-20 | White | 20:1 | 30,000 | A20 | Excellent mechanical strength and elongation, low durometer, for mold making, 3-D casting, potting |
| SCM-30 | White | 20:1 | 40,000 | A30 | Excellent mechanical strength, for mold making, casting, potting |
| SCN-30 | Red | 20:1 | 40,000 | A30 | Fast cure, mid-durometer, for ink-transfer mass, potting |
| SCN-15 | White | 20:1 | 30,000 | A20 | Mid-durometer, for potting |
| SCN-700 | White | 20:1 | 7,000 | A2 | Mid-hardness, for printing pad, potting |
| SCN-125 | White | 20:1 | 12,000 | A50 | Fast cure, for general potting, flat mold-making |
| SPM-616 | White | 20:1 | 9,000 | A62 | Fast cure, for general potting, flat mold-making |
| P/N | Color | Mixing ratio | Mixed Viscosity
(cps, 25℃) | Hardness
(Shore) | Features and Applications..................................... |
|---|---|---|---|---|---|
| ST-323 | Red | 9:1 | 50,000 | A31 | Good mechanical strength and heat resistance. |
| ST-630 | Translucent, blue, white | 1:1 | 6,000 | A32 | Good leveling and mechanical strength for mold-making, potting
. |
| ST-823 | Translucent | 10:1 | 60,000 | A35 | Good mechanical strength, Mold-making. |
| ST-825 | Translucent | 10:1 | 70,000 | A45 | Good mechanical strength, Mold-making, screen printing. |
| P/N | Color | Viscosity
(cps, 25℃) | Hardness
(Shore) | Features.............................................................. |
|---|---|---|---|---|
| SR-501 | Translucent | 1,000 | A22 | Low viscosity, good leveling properties |
| SR-505 | Translucent, Black, White, Red | 5,000 | A18 | Good leveling properties. |
| SR-512 | Translucent, Black, White, Red | 8,000-25,000 | A15 | Good leveling properties. |
| SR-612 | Translucent, Black, White, Red | 25,000 | A15 | General sealing. |
| SR-535 | Translucent, Black, White, Red | 40,000 | A15~25 | General sealing. |
| SR-550 | Translucent, Black, White, Red | 55,000 | A15~25 | General sealing. |
| SR-750T | Translucent | 1,100 | A20 | Excellent flexibility, good mechanical strength for rubber binding |
| SB-442 | White | 70,000 | A75 | 0.8W/mK Good thermal conductive adhesive |
| SB-4421 | White | 70,000 | A85 | 1.5W/mK Good thermal conductive adhesive |
| SB-628 | White | Paste | A90 | 1.6W/mK Good thermal conductive adhesive |
| P/N | Color | Viscosity (cps,25℃) | Hardness (Shore) | Features........................................... |
|---|---|---|---|---|
| SR-8501 | Translucent | 1,000 | A20 | Low viscosity, good leveling properties |
| SR-8505 | Translucent, Black, White, Red | 5,000 | A18 | Good leveling properties |
| SR-8512 | Translucent, Black, White, Red | 10,000 | A15 | Good leveling properties, general sealing |
| SR-8612 | Translucent, Black, White, Red | 25,000 | A16 | General sealing. |
| SR-8535 | Translucent, Black, White, Red | 40,000 | A15~25 | General sealing. |
| SR-8550 | Translucent, Black, White, Red | 55,000 | A15~25 | General sealing. |
| SFR-8100 | Translucent, Black, White, Red | Non-sag | A70 | UL94V0 approval, form-in-place adhesive |
| SFR-8200 | Translucent, Black, White, Red | 380,000 | A65 | UL94V0 approval, sealing |
| SQ-441 | White | 80,000 | A50 | Good thermal conductive interface, low adhesion properties |
| SQ-612-1 | Black, White | 50,000 | A25 | Good mechanical strength, low adhesion properties, easy to rework |
| SR-130 | Strew, Black, Grey, white | Non-sag | A40 | Sealant，excellent adhesion to plastics. |
| P/N | Color | Viscosity(25℃,cps) | Hardness(Shore) | Features............................................................. |
|---|---|---|---|---|
| SFR-3100 | Black, white | Non-sag | A80 | Thermal conductive adhesive 0.8W/mK, UL94V0 approval, form-in place. |
| SR-322 | Transparent | 1,000 | A22 | Low viscosity, good leveling properties |
| SR-318 | Translucent, black, white | Non-sag | A22 | Non-sag sealing, good mechanical strength |
| SR-314 | Translucent, black, white | 8,500~20,000 | A15~A18 | General sealing |
| SR-350 | Translucent, black, white | 50,000 | A20 | General sealing |
| SK-204 | Black, grey, white | Non-sag | A45 | General sealing, car lamp sealing, form-in-place. |
| SK-343 | Black, white | 35,000 | A35 | General sealing |
| SK-345 | Black, white | 70,000 | A45 | General sealing |
| SK-373 | Translucent, black, white | 20,000 | A25 | General sealing |
| SK-376 | Translucent, black, white | 50,000 | A30 | General sealing |
| SK-378 | Translucent, black, white | 80,000 | A30 | General sealing, good mechanical properties. |
| SK-901 | Translucent, black, white | 1,100 | A22 | General sealing, low viscosity, good leveling. |
| SK-3628 | White | 110,000 | A85 | 1.6W/mK High thermal conductive adhesive |
| P/N | Appearance | Properties | Applications............................................................................................... |
|---|---|---|---|
| SFY-350 | White paste | 1.0W/mK Thermal conductive grease | Apply on the base and mounting studs of transistors, diodes, for high voltage corona-suppressant coating in connections of heat source and heat sink
|
| STG-4W | Grey paste | 4.0W/mK Lighten Thermal conductive grease | Apply on the base and mounting studs of transistors, diodes, for high voltage corona-suppressant coating in connections of heat source and heat sink
|
| SFY-635 | Grey paste | 2.0W/mK Lighten Thermal conductive grease | Apply on the base and mounting studs of transistors, diodes, for high voltage corona-suppressant coating in connections of heat source and heat sink
|
| SFY-636 | White paste | 2.0W/mK Lighten Thermal conductive grease | Apply on the base and mounting studs of transistors, diodes, for high voltage corona-suppressant coating in connections of heat source and heat sink
|
| SFY-650 | White paste | 1.1W/mK Lead-free thermal conductive grease | Apply on the base and mounting studs of transistors, diodes, for high voltage corona-suppressant coating in connections of heat source and heat sink
|
| STG-710 | White paste | 1.2W/mK Lead-free thermal conductive grease, reach UL94V0 level | Apply on the base and mounting studs of transistors, diodes, for high voltage corona-suppressant coating in connections of heat source and heat sink
|
| S-01 | Red paste | Red color paste | Colorants for silicones
|
| S-02 | White paste | White color paste | Colorants for silicones
|
| SN-03 | Yellow paste | Yellow color paste | Colorants for silicones
|
| S-05 | Black paste | Black color paste | Colorants for silicones
|
| SN-06 | Orange paste | Black color paste | Colorants for silicones
|
| SMA-10 | Yellow liquid | Matting agent | Matting agent |
| SFY-PR4 | Yellow liquid | Primer to many kinds of materials | Improves adhesion |
| SWR-317 | Haze Liquid | Excellent waterproof and weather resistance | Water repellent. |
