FONG YONG Chemical Co., Ltd

Safety   Quality   Stability

Silicones Epoxy Resins UV Curable Resins

Epoxy Resins

UL 94V-0Grade(Insulation Potting, Casting, Encapsulating)

P/N ColorMixing ratio (cps,25℃)ViscosityFeatures and Applications............................................................
E-759-1/H-759-1Black100:4040,000/300Mild-soft, excellent impact strength.
E532-1A/H532-1BBlack100:157,500/30For potting.
E536/H536Black100:30 25,000/40high voltage resistance, high temperature resistance up to 150℃,
good thermal conductivity 0.5 W/mk.
E537-A/H537-BAll colors100:30300,000/200Mid-high temperature curing schedule, high voltage resistance.
E759/H759All colors100:3018,000/120Mid soft, for potting.
E-5322/H-5322White,black100:50 6,500/200For potting.
E532/H532All colors100:15 20,000/20For potting.

1-Part (IC Encapsulating, Adhesive, Confidential series)

品名顏色 黏度特性及用途............................................................................
EP-819Black 40,000-80,000Can be cured at lower temperature (80℃~100℃), adhesive for electronic parts assembling.
EP-815Red thixotropy50,000-100,000Fast cure, short-term high temperature resistance (280℃), SMT, screen printable.
EP-0606Black, white30,000-50,000Can be cured at lower temperature (80℃~100℃), leveling, IC sealing,
adhesive for electronic parts assembling.
EP-10-CBlack80,000Mid-high temperature curing schedule, excellent adhesive properties, for IC encapsulation and electronic part adhesion.
EP-10C#7Black pasteNon-sagMid-high temperature curing schedule, excellent adhesive properties, for IC encapsulation and electronic part adhesion.
EP-1109-11BlackOne partCarbon conductive adhesive.
EP-1109-14CopperOne partCopper conductive adhesive.

Rigid (Electronics, Electrics, Insulation, Potting, Casting, Encapsulating, Thermal Conductive, Adhesive)

P/N ColorMixing ratio (cps,25℃)ViscosityFeatures and Applications.............................................................................................................
E-128B/H-128Black  3:1 5,000/60Good weather resistance, high tensile strength, for potting, casting.
E-190B/H-190Black 100:404,400/100 Excellent dielectric properties, high voltage resistance, for large electric component potting.
E-226/H-120All colors100:40-50Paste/1,200Non-sag, easy to operate, for large electric component adhesive and dipping.
E-8066B-1/H-8066-1White,black4:19,000/100-150Excellent weather resistance, high gloss, for electric component potting and thin layer coating, and binding.
E-590B-1/H-590Black  5:125,000/110Excellent weather resistance, high thermal conductivity, for insulation and potting of where weather resistance is required.
E-130B/H-130Black 3:1  3,000/20Long pot life, for electric component sealing, potting, casting.
E-130B/H-132Black 2:13,000/35High tensile strength, low viscosity, for insulating, potting, casting, general purpose.
E-5600B/H-P2Black 2:14,500/40Easy to use, excellent dielectric properties, thermal resistance, for electronic and electric insulation, potting, and casting.
E-120C/H-100All colors3:11,200/20Easy to use, low viscosity, general purpose.

E-1009/H-1009All colors3:1Paste/100Mid-viscosity, high temperature resistance, high thermal conductive, heat cure, for large electric component potting.
E-638/H-638All colors100:28Paste/110High viscosity, heat cure type with thermal resistance, high thermal conductivity, for high voltage ignition coil of automobile vehicles.
E-566B/H-566Black 3:12,500/600Mid viscosity, high voltage resistance, high thermal conductive, low temperature resistance, for high voltage ignition coil of automobile vehicles, CDI, rectifier regulator.
E-311W/H-311White2:115,000/12,000Thermal conductive adhesive, 0.8 W/mk.

E-700/H-190transparent2:1 6,000/100High transparency, long pot life, no heat generation.

E-999B/H-999Black4:16,000/50-100Mid viscosity, low cost.

Flexible (Electronics, Electrics, Insulation, Encapsulating, Potting, Casting, Thermal Conductive, Adhesive)

P/N ColorMixing ratio (cps,25℃)ViscosityFeatures and Applications ...................................................................................................................................
E-185BCS/H-185CSWhite,black3:11,050/40Easy to use, low viscosity, good elasticity, for potting and insulation of delicate circuit of electronic components.
E-721/H-721All colors1:1900/200Low viscosity with high tensile strength, elastic, low stress, for casting of delicate circuit of electronic components.
E-733/H-733All colors1:1 5,000/500High flexibility, potting material for electronic and electric components.
E-750/H-750All colors1:18,000/120General use, semi-soft.
E-766/H-766All colors100:306,000/80High strength, potting material for automobile vehicles and electronic components.
E-768B/H-768Black, white100:602,800/100Good weather resistance especially for low temperature, good flexibility, room temperature cure, good dielectric properties for potting of electronic components.
E-7311B/H-7311Black, transparent100:304,000/100Easy to use, good impact strength, low temperature resistance, for insulating
and potting of electrical and electronic components.
E-806B/H-806Black100:2520,000/300Soft, low temperature stable (-30oC), for potting and insulation of delicate circuit of electronic components.

Light-emitting Diode (LED Encapsulating)

P/N ColorMixing ratio (cps,25℃)ViscosityFeatures and Applications................................................................................
E-600/H-600Transparent 1:110,000/110High transmittance, excellent thermal resistance, for casting of light-emitting diode and small LED.
E-605/H-605Transparent 1:110,000/100High transmittance, excellent thermal resistance, for casting of light-emitting diode and small LED.
E-606/H-606Transparent 1:110,000/100High transmittance, excellent thermal resistance, for casting of light-emitting diode.
E600C/H-600Transparent 1:14,500/100Insulation material, for insulator coil, insulator paper, and insulator cloth.
E-601/H-601TTransparent 1:110,000/120High transparency, for LED encapsulation.

Epoxy Doming Resins – Rigid
(Decorative Accessories, Gifts, Imitated Enamels, Printings, Coatings)

P/NColorMixing ratio(cps,25℃)
Viscosity		Features and applications.........................................................
E-0001/H-0001Transparent
3:11,900/20Low viscosity, high transparency, for metals coating.
E-110/H-101Transparent

3:111,000/30Cold (imitated) enamel coating, low viscosity.
E-110-1/H-101-1Transparent

3:15,000/30Cold (imitated) enamel coating, low viscosity, for cold weather.
E-126/H-100Transparent

3:13,500/20Mid viscosity, excellent adhesive properties to metals and plastics.
E-138/H-138Transparent

3:11,500/20Cold enamel coating, low viscosity, long pot life.
E-101/H-620Transparent

3:1800/20Low viscosity, long pot life, good leveling.
E-126/H-875Transparent

3:13,500/60Fast cure, short pot life.
E-9/H-9Transparent

2:14,000/35Mild, easy to use, for printings or large surface coating.
E-955/H-6201Transparent

3:11,800/20Large size coating.
E-127/H-620Transparent

10:4/2:13,500/20Excellent transparency, mild, excellent weather resistance.
E-1500/H-120CTransparent

2:1600/600Excellent transparency, replacing lacquer, for UV cure printing.
E-132/H-TKTransparent

2:1-24,000/300For diamond adhesive.
E-19/H-19Transparent

4:1600/1003D doming, good UV resistance.
E-1006T/H-190Transparent

3:11,500/75Hard type, good yellowing resistance, for high transparent coating, doming and potting.
E-165/H-191Transparent
3:13000/80Excellent weather resistance, slower chemical reaction, suitable for larger castings and pottings.

Epoxy Doming Resins – Flexible (Non-sag, Decorative Accessories, Gifts, Printings, Coatings)

P/N ColorMixing ratio(cps,25℃)
Viscosity		Features and applications................................................
E-229/H-229Light white, transparent2:15,500/3,000Non-sag, hard type for convex coating.
E-126/H-229SLight yellow3:15,600/Non-sagNon-sag, hard type.
E-1140/H-1140Transparent3:11,100/60Soft type, fast cure, for 3D doming.
E-1160/H-1160Transparent3:11,250/65Semi-soft type, glossy surface, screen printable.
E-1166/H-1166Transparent3:11,000/25Low viscosity, very soft for 3D doming.
E-1188TT/H-1188Transparent3:11500/75Soft type, good yellowing resistance, for high transparent coating, doming and potting.
E-1155/H-1155Transparent100:25-331,500/30Good flexibility, mixing ratio adjustable.
E-1156/H-1156Transparent3:1 3,000/70Soft type, for 3D doming.
E-1148/H-1148Transparent2:11,100/100Soft type, fast cure, mild, screen printable.
E-440/H-440Transparent3:17,000/30General use, for high height doming.
OX800A/B Variety
1:1-2100/PowderSoft PVC, for photo frame, key chain, thermal pad.

Epoxy Resins Series (Constructions, Coatings)

P/N ColorMixing ratio(cps,25℃)Viscosity Features and Applications..............................................................
E-110/H-116Light brown2:112,000/4,000High mechanical strength, mid-high viscosity, for repairing, filling of constructions.
E-1101/H-1101Light brown 1:111,000/11,000General use, for resin slurries, bumped roadways.
E-238/H-238 Grey 1:1 No-sag/4,000 Non-sag, fast cure, high performance construction use adhesive, for glisten signs.
E-6002/H-6002 All colors 4:113,000/1,100 Acid Alkali resistant coatings.
E-505/H-505Light yellow clear 10:1 8,000/2,500Clear spray, for ceramics and metals coating.
X-75A/X-75B All colors 10:3 7,500/600Dust-free floor, general use for metals and hardware coating.
E-226/H-226Light yellow brown2:1Paste/4,000Non-sag, excellent adhesive properties.
E-050/H-050Light yellow brown2:1 4,000/1,000Low viscosity, fast cure, for wall reinforcement.
E-A8G/H-A8 All colors 5:112,000/50 For constructions.
EX-0504/HX-0504 All colors 2:1 2000/200Floor coating and wall coating for leakproof.
EX-0723-1/HX-0723-1White,brown 2:1 35000/60000 Air filter adhesive.
